Description
The Marlin 7 is your best friend on the trail and wherever else you roll thanks to its confidence-boosting trail geometry. It finds the perfect balance between price and performance with a RockShox suspension fork that makes quick work of rocks and bumps in your path, and loads of gears from the SRAM NX Eagle 12-speed drivetrain.
Please note: spec in the product illustration is not accurate
It’s right for you if…
You want a go-anywhere trail bike that’s got upgrades where it matters most, but won’t break the bank. You want to build skills on the trail, and need a bike with confidence-inspiring geometry.
The tech you get
A lightweight aluminium frame with modern trail riding geometry and internal routing that keeps cables protected and keeps the bike looking sleek. A 100 mm RockShox Judy suspension fork that smooths out rowdy trails, upgraded 12-speed SRAM NX Eagle shifting and the serious stopping power of hydraulic disc brakes.
The final word
The Marlin 7 is the go-to trail bike for those wanting to build skills on the singletrack and get the best bang for their bucks with upgraded suspension and confidence-inspiring geometry.
Why you’ll love it
- You get real-deal modern mountain bike geometry that keeps handling confident when you’re on singletrack, but is versatile enough for use on roads and bike trails too
- You get a RockShox fork with 100 mm of suspension that turns rocks and roots in the trail into smooth-sailing and upgraded 12-speed SRAM Eagle shifting
- Mudguard mounts make it easy to accessorise, so your mountain bike can double as a rugged commuter
- Internal routing makes it easy to add a dropper post that lets you lower your saddle on the fly for more confident descending
- Marlin models in sizes XXS and XS have a curved top tube and lower standover height that makes it easier for smaller riders to mount and dismount
Why we won’t ship Trek Bikes
Specifications
| *Frame | Size: XS Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew |
|---|---|
| Size: S , M , ML , L , XLAlpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew | |
| *Fork | Size: XS , SRockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5″ wheel, 100 mm QR, 100 mm travel |
| Size: M , ML , L , XLRockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel |
| Hub front | Formula DC-20 LW, alloy, 6-bolt, 5×100 mm QR |
|---|---|
| Hub rear | Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm QR |
| Skewer rear | 173×5 mm QR |
| *Rim | Size: XS , S , M , ML , L , XL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve |
| Size: M , ML , L , XL Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve |
|
| *Tyre | Size: XS , S Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5×2.40” |
| Size: M , ML , L , XL Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29×2.40” |
|
| Rim strip | Bontrager TLR |
| Shifter | SRAM SX Eagle, 12-speed |
|---|---|
| Rear derailleur | SRAM NX Eagle, 12-speed |
| *Crank | Size: XS , S , M SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length |
| Size: ML , L , XL SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length |
|
| Bottom bracket | Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle |
| Cassette | SRAM PG-1210 Eagle, 11-50, 12-speed |
| Chain | SRAM SX Eagle, 12-speed |
| Pedal | VP-536 nylon platform |
| Saddle | Bontrager Verse Short, stainless steel rails |
|---|---|
| *Seatpost | Size: XS , S TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm, 350 mm length |
| Size: M TranzX JD-YSI34, 125 mm travel, internal routing, 34.9 mm, 405 mm length |
|
| Size: ML , L TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm, 456 mm length |
|
| Size: XL TranzX JD-YSI34, 170 mm travel, internal routing, 34.9 mm, 500 mm length |
|
| *Handlebar | Size: XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width |
| Size: S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width |
|
| Size: M , ML , L , XL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
| Grips | Trek Line Comp, nylon lock-on |
| *Stem | Size: XS , S Bontrager Comp, 31.8 mm, 7-degree, 35 mm length |
| Size: M , ML , L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
|
| Size: XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length |
|
| Head set | Semi-integrated, 1-1/8″ |
| Brake | Shimano MT200 hydraulic disc |
| *Brake rotor | Size: XS , S , M , ML , L , XL Shimano RT26, 6-bolt, 160 mm |
| Size: M , ML , L , XL Shimano RT26, 6-bolt, 180 mm |
|
| Brake Set | Shimano MT200 hydraulic disc |
| Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
|---|
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
